g030686
Figure12
1.Rubberisolator2.Right,rearmount
Note:Usesoapywaterandamallettoassistwith
insertingtherubberisolatorintothehole.
3
ApplyingtheFoamSeals
Partsneededforthisprocedure:
1
Left,frontfoamseal
1
Center,frontfoamseal
1
Right,frontfoamseal
1
Leftfoamseal
1
Rightfoamseal
1
Lefttankfoam
1
Righttankfoam
1
Left,rearfoamseal
1
Right,rearfoamseal
1
Rearfoamseal
ApplyingtheFrontFoamSeals
Applythecenter,frontfoamsealandthentheleft,
frontandright,frontfoamsealsapproximately3mm
(1/8inch)fromtheedgeonthefrontofthecabunit
(Figure13).
g030692
Figure13
1.Applicationarea
3.Center,frontfoamseal
2.Left,frontfoamseal4.Right,frontfoamseal
Note:Installtheendsofthefoamsealstointerlock
andcreateasolidseal.
ApplyingtheSideFoamSeals
1.Applytheleftfoamsealapproximately3mm
(1/8inch)fromtheedgeonthefront,leftsection
ofthecabunit(Figure14).
Note:Installtheendsofthefoamsealsto
interlockandcreateasolidseal.
g030702
Figure14
1.Applicationarea
2.Leftfoamseal
2.Applytherightfoamsealapproximately3mm
(1/8inch)fromtheedgeontheright,front
sectionofthecabunit.
Note:Installtheendsofthefoamsealsto
interlockandcreateasolidseal.
8
