Chapter
4
Product
Overview
G403841
Engine
hood
Operator's
seat
Control
arm
Steering
wheel
Seat-adjustment
lever
Front
cutting
units
Rear
cutting
units
Controls
G467744
Key
switch
Lower
mow/raise
control
lever
PTO
switch
Headlight
switch
Engine-speed
switch
InfoCenter
Brake
pedal
Pedal-locking
latch
Parking-brake
pedal
T
raction
pedal
T
ilt-steering
pedal
Product
Overview
Page
4–1
3466-702
A
37
39
