Pushing or Towing the Machine Forward
1. Open the hood and remove the center shroud.
2. Open the tow-bypass valve
by rotating it 90° (1/4 turn) in either direction.
Note: Note the position of the valve when opening and closing it.
G424062
3. Push or tow the machine forward.
IMPORTANT
Do not push or tow the machine faster than 3 to 4.8 km/h (2 to 3 mph) or for more than
0.4 km (1/4 mile), because damage to the hydraulic system may occur. The bypass
valve must be open whenever you push or tow the machine.
4. When the machine is ready for operation, close the tow-bypass valve by rotating it back
90° (1/4 turn) before starting the engine.
Note: Do not exceed 7 to 11 N∙m (5 to 8 ft-lb) torque to close the valve.
3466-702A Page 5–37 Operation: Pushing or Towing the Machine
