Toro Emotion - Replacing the Blade; Emptying the Fuel Tank

Figure29
1.Adjustingnut2.Lockingnut
2.Usetheadjustingnuttoadjusttheselfpropeldrive.
•Iftherearwheelsdonotrotatebackwardwhen
youpullthemowerbackward,turntheadjusting
nut1to3turnscounterclockwise(fromthe
operatingposition),dependingontheamount
ofcorrectionneeded.
•Ifthemowerdoesnotself-propel,turnthe
adjustingnut1to3turnsclockwise(fromthe
operatingposition),dependingontheamount
ofcorrectionneeded.
3.Startthemowerandusetheself-propeldriveto
checktheadjustment.
Note:Iftheself-propeldriveisnotproperly
adjusted,repeatstep2.
4.Whentheself-propeldriveisproperlyadjusted,
tightentheadjustingnutbyhand.
Note:Ifyourmowerstilldoesnotproperlyself-propel
afterperformingthisprocedure,contactanAuthorized
ServiceDealer.
ReplacingtheBlade
ServiceInterval:Every25hours—Replacetheblade
orhaveitsharpened(morefrequently
iftheedgedullsquickly).
Important: Y ou will need a torque wr ench to install
the blade pr oper l y .Ifyoudonothaveatorque
wrenchorareuncomfortableperformingthis
procedure,contactanAuthorizedServiceDealer.
Examinethebladewheneveryourunoutofgasoline.If
thebladeisdamagedorcracked,replaceitimmediately.
Ifthebladeedgeisdullornicked,haveitsharpenedor
replaceit.
WARNING
Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.
Weargloveswhenservicingtheblade.
1.Disconnectthesparkplugwirefromthesparkplug.
RefertoPreparingforMaintenance.
2.Tipthemowerontoitssidewiththeairlterup
(Figure30).
Figure30
3.Removetheblade,savingallmountinghardware.
4.Installthenewbladeandallmountinghardware.
Important:Positionthecurvedendsofthe
bladetopointtowardthemowerhousing.
5.Useatorquewrenchtotightenthebladebolt
to50N-m.
Important:Whileholdingthebladewitha
blockofwood,putyourweightbehindthe
ratchetorwrenchandtightentheboltsecurely.
EmptyingtheFuelTank
1.Stoptheengineandwaitforittocooldown
2.Disconnectthewirefromthesparkplug.
3.Removethecapfromthefueltank.
4.Useahandpumptosyphonthefuelintoaclean
approvedgasolinecontainer.
5.Connectthewiretothesparkplug.
16
