Figure8
2.Slowlypouroilintotheoillltubeuntiltheoillevel
reachestheFullmarkonthedipstick(Figure8).
Donotoverll.(Max.ll:0.59l,type:SAE30
detergentoilwithanAPIserviceclassicationofSF,
SG,SH,SJ,SL,orhigher.)
3.Installthedipsticksecurely.
Important:
Change the engine oil after the r st
5 operating hour s ;changeityearlythereafter.
RefertoChangingtheEngineOil.
5
InstallingtheFuse
NoPartsRequired
Procedure
Model21027only
Yourmowercomeswitha40-ampfusethatprotectsthe
electricstarter.
Important:Youcannotstartthemowerwiththe
electricstarterorchargethebatteryunlessyou
installthefuse.
1.Openthebatterycover(Figure9).
Figure9
1.Batterycover3.Fuse
2.Fuseholder
2.Locatethefuseholderfromtheupperleftcornerof
theopeningtothebatterycompartment(Figure9).
Note:Thewiretothefuseholderisshort;youwill
notbeabletopullthefuseholderfullyoutofthe
batterycompartment.
3.Installthefuseinthefuseholder(
Figure10).
