Toro Greensmaster eFlex 1018 - Table of Contents

ThisproductcomplieswithallrelevantEuropean
directives.Fordetails,pleaseseetheDeclarationof
Incorporation(DOI)atthebackofthispublication.
Introduction
Thiscuttingunitisdesignedforcuttingturfongreens
andsmallfairwaysofgolfcourses.Usingthisproduct
forpurposesotherthanitsintendedusecouldprove
dangeroustoyouandbystanders.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Visitwww.Toro.comforproductsafetyandoperation
trainingmaterials,accessoryinformation,helpnding
adealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
g308510
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Safety.......................................................................3
GeneralSafety...................................................3
CuttingUnitSafety..............................................3
BladeSafety.......................................................3
SafetyandInstructionalDecals..........................3
Setup........................................................................4
1InstallingtheRoller..........................................4
2InstallingtheCuttingUnittotheTraction
Unit.................................................................4
3AdjustingtheCuttingUnit.................................4
ProductOverview.....................................................5
Specications....................................................5
Attachments/Accessories...................................5
Operation..................................................................5
Maintenance.............................................................6
AccessingtheCuttingUnit..................................6
CheckingtheReel-DriveshaftGrease
Point................................................................6
AdjustingtheBedknife-to-ReelContact..............7
SettingtheCuttingUnittoMatchTurf
Conditions.......................................................8
PerformingtheHeight-of-CutAdjustment...........9
AdjustingtheClipRate......................................11
AdjustingtheCut-OffBar..................................12
ServicingtheBedbar........................................13
ServicingtheBedknife......................................14
BacklappingtheCuttingUnit.............................16
©2019—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
2
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved
