Toro Greensmaster eFlex 1018 - Setup; Installing the Roller; Installing the Cutting Unit to the Traction Unit; Adjusting the Cutting Unit

Setup
1
InstallingtheRoller
NoPartsRequired
Procedure
Thecuttingunitisshippedwithoutafrontroller.
ObtainarollerfromyourauthorizedT orodealerand
installitonthecuttingunit,asfollows:
1.Removetheplowbolt,washer,andangenut
securingoneoftheheight-of-cutarmstothe
cuttingunitsideplate(Figure3).
g310842
Figure3
1.Roller4.Adjustingscrew
2.Plowbolt5.Flangenut
3.Height-of-cutarm
6.Roller-mountingscrew
2.Loosentheroller-mountingscrewsinthe
height-of-cutarms.
3.Slidetherollershaftintotheheight-of-cutarm
ontheoppositeendofthecuttingunit.
4.Slidetheheight-of-cutarmontotherollershaft.
5.Looselysecuretherollertothecuttingunitwith
theheight-of-cutarmandfastenerspreviously
removed.
6.Centertherollerbetweentheheight-of-cutarms.
7.Tightentheroller-mountingscrews.
8.Adjusttothedesiredheight-of-cutandtighten
theheight-of-cutarmmountingfasteners.
2
InstallingtheCuttingUnit
totheTractionUnit
NoPartsRequired
Procedure
Installthecuttingunittothetractionunit;referto
yourtractionunitOperator’sManualforinstallation
instructions.
3
AdjustingtheCuttingUnit
NoPartsRequired
Procedure
1.Accessthecuttingunit;refertoAccessingthe
CuttingUnit(page6).
2.Adjustthebedknifetothereel;refertoAdjusting
theBedknifeafterGrinding,Backlapping,or
Disassembly(page8).
3.Adjusttheheightofcut;refertoPerformingthe
Height-of-CutAdjustment(page9).
4
