Troubleshooting
Problem Possible Causes Corrective Action
The unit will not move when the
traction ball is engaged.
1. Check that motion occurs at the
pump pivot plate when the
traction ball is moved.
1. Inspect the traction push/pull
cable and override assembly
under the tiller handle.
2. The oil level in the hydraulic
reservoir (gearbox) is low.
2. Replenish, if necessary.
3. Bypass valve is not fully closed. 3. Close the valve.
4. The traction drive belt tension
is incorrect.
4. Adjust the belt tension.
The unit will not transport at full
speed.
1. The unit is not fully raised to
the transport position.
1. Hold the lift toggle switch until
the slip clutch in the actuator
can be heard ratcheting and
the spindle lift arms are nearly
vertical with the rear axle
spindle tipped away from the
engine.
2. The oil level in the hydraulic
reservoir (gearbox) is low.
2. Replenish, is necessary.
3. Bypass valve is not fully closed. 3. Close the valve.
4. The traction drive belt tension
is incorrect.
4. Adjust the belt tension.
5. Check that motion occurs at the
pump pivot plate when the
traction ball is moved.
5. Inspect the traction push/pull
cable and override assembly
under the tiller handle.
The engine dies during startup.
1. The fuel shut-off valve is
closed.
1. Open the fuel shut-off valve.
2. Fuel in the fuel tank is low. 2. Replenish, if necessary.
3. The engine choke is not
operating correctly.
3. Check the choke connections
and operation. Regulate the
choke until the engine is warm
when starting a cold engine.
4. Check the engine oil level. 4. The oil pressure switch is
bypassed during start, but must
activate to protect the engine
while running.
5. Starting conditions are cold
(30°).
5. Multiple start attempts may be
required to trip the oil pressure
switch.
