A2-5TimeCutter Z / Precision Z Service Manual
SPECIFICATIONS
2
Item Specifi cation
Mower Decks 38” (97cm) cut, right side discharge, two blade mid-mount rotary. Drawn 13 gauge steel
deck with welded mounting brackets. Frame supported.
42” (107cm) cut, right side discharge, two blade mid-mount rotary. Drawn 13 gauge
steel deck with welded mounting brackets. Frame supported.
44” (112cm) cut, right side discharge, two blade mid-mount rotary. Drawn 13 gauge
steel deck with welded mounting brackets. Frame supported.
Blade Tip Speed Model Speed
Z320H/Z310 16,760 ft/min @3300 RPM nominal, 17,270 ft/min @ 3400 RPM
max.
Z330LX/Z340HLX 17,290 ft/min @ 3300 RPM nominal, 17,810 ft/min @ 3400 RPM
max.
Z350HLX 16,740 ft/min @ 3300 RPM nominal, 17,310 ft/min @ 3400 RPM
max.
Height-of-Cut Seven height-of-cut positions from 1.5” (38mm) to 4.5” (114mm), 1/2” (12.7mm)
increments.
Electrical System Battery Voltage: 12 volt negative ground
Battery Type: BCI Group U1
