Lubrication
GreasingtheBearings
ServiceInterval:Every25hours—Greaseall
lubricationpoints.
GreaseType:No.2lithiumgrease
1.Parkthemachineonalevelsurfaceand
disengagetheblade-controlswitch.
2.Movethemotion-controlleversoutwardtothe
PARKposition,shutofftheengine,removethe
key,andwaitforallmovingpartstostopbefore
leavingtheoperatingposition.
3.Cleanthegreasettings(Figure29andFigure
30)witharag.
Note:Makesuretoscrapeanypaintoffthe
frontofthetting(s).
g032432
Figure29
1.Frontcastertire
decal106-8717
Figure30
Locatedontheseat-panunderside
1.Readtheinstructions
beforeservicingor
performingmaintenance.
3.Greaseevery25operating
hours.
2.Checkthetirepressure
every25operatinghours.
4.Engine
4.Connectagreaseguntoeachtting(Figure29
andFigure30).
5.Pumpgreaseintothettingsuntilgreasebegins
tooozeoutofthebearings.
EngineMaintenance
EngineSafety
Shutofftheenginebeforecheckingtheoiloradding
oiltothecrankcase.
ServicingtheAirCleaner
ServiceInterval:Beforeeachuseordaily—Check
theaircleanerfordirty,looseor
damagedparts.
Every50hours—Servicetheair-cleanerpaper
element(moreoftenunderextremelydusty,
dirtyconditions).
Every100hours—Replacetheair-cleaner
paperelement(moreoftenunderextremely
dusty,dirtyconditions).
Thisengineisequippedwithareplaceable,
high-densitypaperair-cleanerelement.Checkthe
aircleanerdailyorbeforestartingtheengine.Check
forabuildupofdirtanddebrisaroundtheair-cleaner
system.Keepthisareaclean.Also,checkforlooseor
damagedcomponents.Replaceallbentordamaged
air-cleanercomponents.
Note:Operatingtheenginewithlooseordamaged
air-cleanercomponentscouldallowunlteredairinto
theengine,causingprematurewearandfailure.
1.Rotatethelatchesoutward.
2.Removethecovertoaccesstheair-cleaner
element(Figure31).
3.Removetheelement,andgentlytaptheelement
todislodgedirt.
Note:Donotwashthepaperelementoruse
pressurizedair,asthiswilldamagetheelement.
Note:Replaceadirty,bent,ordamaged
element.Handlethenewelementcarefully;
donotuseifthesealingsurfacesarebentor
damaged.
4.Cleantheair-cleanerbaseasrequiredand
checkthecondition.
5.Installthepaperelementontotheair-cleaner
base.
6.Installthecoverandsecureitwiththelatches
(Figure31).
