Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Nopartsrequired
–
Unfoldthehandle.
Screw
3
Chuteassembly
1
2
Discharge-chutehandle1
Installthedischargechute.
1
UnfoldingtheHandle
NoPartsRequired
Procedure
1.Loosenthehandleknobs,pullouttheU-shapedhandle
locksuntilyoucanmovethehandlefreely,androtate
thehandletotheoperatingposition(Figure4).
Figure4
1.U-shapedhandlelock(2)
2.Handleknobs
2.InserttheendoftheU-shapedhandlelockintothe
openholeinthehandleandtightenthehandleknobs
untiltheyaresnug(Figure5).
Note:Thehandleknobscontainnylocnutsthat
requiremorepressuretotightenfullytopreventthe
handlefromcominglooseduringoperation.
Figure5
Important:Ensurethatyoudonotpinchorkink
thecontrolcable(Figure6).
Figure6
1.Controlcable
