InstallingtheDischargeChute
Partsneededforthisprocedure:
3
Screw
1
Chuteassembly
1Discharge-chutehandle
Procedure
Installthedischargechuteasshown(Figure7).
Figure7
1.Dischargechute
2.Screw(3)
Note:Foreasierinstallation,useasmallratchetwrenchto
tightenthescrews.
Important:Donotovertightenthescrews;otherwise
youmaydamagethedischargechuteandpreventit
fromturningfreely.
3
FillingtheEnginewithOil
NoPartsRequired
Procedure
Yourmachinedoesnotcomewithoilintheengine,butit
doescomewithabottleofoil.
Important:Beforestartingtheengine,lltheengine
withoil.
Note:Thebottleofoilmaycontainmoreoilthanisrequired.
Donotoverllorunderlltheengine.
Maxll:.0.60L(20oz),type:automotivedetergentoilwith
anAPIserviceclassicationofSJ,SL,orhigher.
UseFigure8belowtoselectthebestoilviscosityforthe
outdoortemperaturerangeexpected.
Figure8
1.Movethemachinetoalevelsurface.
2.Cleanaroundtheoil-llcap(Figure9).
Figure9
1.Oil-llcap
3.Unscrewtheoil-llcapandremoveit.
4.Withthemachineintheoperatingposition,carefully
pouroilintothecrankcaseuntilthepointofoverow .
Note:Youmaytipthemachineforward(handleup)
tomakeaddingoileasier.Remembertoreturnthe
machinetotheoperatingpositionbeforecheckingthe
oillevel.
Important:Donottipthemachinealltheway
forwardontoitsnose,orfuelmayleakoutofthe
machine.
5.Wait3minutesfortheoiltosettleandaddenoughto
bringittothepointofoverow.
6.Screwtheoil-llcapintotheoil-llholeandtightenit
securely.
