ProductOverview
g192115
Figure3
LeftSideofChainSaw
1.Chain
6.Batterypack
2.Guidebar
7.Triggerlock
3.Oilwindow8.Trigger(onrearhandle)
4.Oilcap9.Guidebarcover
5.Fronthandle
g192114
Figure4
RightSideofChainSaw
1.Chainbrake
3.Wingnut
2.Chaintensioningknob
Specications
AppropriateTemperatureRanges
Chargethebatteryat0°C(32°F)to40°C(104°F)*
Useproductsat
-15°C(5°F)to60°C(140°F)
Storeproductsat-15°C(5°F)to60°C(140°F)
UnplugthechargerifBelow0°C(32°F)orabove
40°C(104°F)
*Chargingtimewillincreaseifyoudonotchargethe
batterywithinthisrange.
Storethetool,batterypack,andbatterychargerinan
enclosedclean,dryarea.
Operation
BeforeUsingtheChainSaw
Beforeusingthechainsaw,dothefollowing:
•Checkthechaintension;refertoAdjustingthe
ChainT ension(page17).
•Cleanandcheckthechaincomponentsfor
excessivewearordamageandreplacethemas
needed;refertoServicingtheGuideBar,Chain,
andDriveSprocket(page17)andSharpeningthe
Chain(page19).
•Checktheoillevel;refertoCheckingtheOilLevel
andAddingBarandChainOil(page16).
•Checkthechainbrake;refertoCheckingthe
ChainBrake(page16).
StartingtheChainSaw
1.Makesurethattheventsonthechainsaw
(Figure5andFigure6)arefreefromdustand
debris.
g197204
Figure5
1.Vent
g197205
Figure6
1.Vent(insidethebattery
cavity)
2.Vent
8
