Toro Prior LC1P65FA - Electrical System Wiring

40
Electrical System Wiring (Electric Start Shown)
A Ignition Coil
B Starter Motor
C Alternator
D Brake / Kill Switch
E Starter Interlock Switch
F To Chassis Harness
G To Ground
