Toro Pro Sweep 07068 - Reviewing the Machine Requirements; Removing the Hitch Tongue and Hydraulic Cylinder from the Shipping Position; Installing the Hitch Tongue

MediaandAdditionalParts
Description
Qty.
Use
Operator'sManual
1
Readthemanualbeforeoperatingthemachine.
CEcerticate
1
ThisdocumentindicatesCEcompliance.
Remotecontrol1Usetheremotecontroltooperatethemachine.
1
ReviewingtheMachine
Requirements
NoPartsRequired
Procedure
•Themachinecanbetowedbymostutilitytractors
equippedwithhydraulicsproducing26.5to30
L/min(7to8gpm)at13,790kPa(2,000psi)
andotationtiresforoperationovergolfgreens.
Ensurethatthetractorhasadequatebrakesanda
drawbarhitchcapacitytohandlea1587kg(3,500
lb)trailer.RefertothetowingvehicleOperator's
Manualfortowinginstructionsandprecautions.
•TheWorkmanvehiclerequirestheHigh-Flow
HydraulicsKit.Workmanvehicleswithserial
numberspriorto900000001requiretheHeavy
DutyDrawbar(Model44212or44213)installed.
Note:The4WDWorkmanmodelisthebestfor
hillyorbermedapproachestogreens.
Important:ForoldermodelWorkman
vehicles,donotattempttopullthemachine
whenloadedwithmaterial,withthestandard
Workmanhitch.Itisonlyratedto680kg(1,500
lb)andmaybendordamagethecrosstube
axlesupportorrearspringshackles.Always
usetheDrawbarKitforHeavy-DutyWorkman
Vehicles(Model44212)orHitchFrameand
DrawBarKitforHeavy-DutyWorkmanVehicles
(Model44213).
Important:Donotattempttowingaloaded
machinewithalightutilityvehicleorrun-about.
Thesemachinesdonothaveadequatebrakes,
suspension,orframestrengthtohandlethe
weightofthemachine.
•Trailerbrakesarerecommendedwhenusing
themachineinhillyterrain.Whenfullyloaded,
themachinemayweighasmuchas1,588kg
(3,500lb)(GVW).Thisweightishigherthanthe
recommendedtowingandbrakinglimitofmost
utilityvehicles.Atrailerbrakekitisavailablefor
directinstallationwiththeWorkmanvehicle.
Note:Thetrailerbrakekitcanbeadaptedto
othervehicleswitha12Vbrakelightsource.
2
RemovingtheHitchTongue
andHydraulicCylinder
fromtheShippingPosition
NoPartsRequired
Procedure
Note:Have2peopleremovethehitchassembly.
1.Chockthewheelsofthemachine.
2.Removethepinassembly,boltandnutsecuring
thehydrauliccylinderandhosestothehitch
tongueforshipping.Also,cutthecabletie.
Carefullylowerthecylinderandhosesfromthe
tongue.Retainthepinassemblyandfasteners
forre-use.
3.Removethehairpincotterandhitchpinsecuring
thehitchtonguetotheuppershippingbracket.
Thehitchtongueisveryheavy,usecaution
whenremovingthetonguefromtheshipping
brackets.
4.Pivotatthelowershippingpinandpivotthe
tonguedown.
5.Removethepinassembly,boltandnutsecuring
thehitchtonguetothelowershippingbracket.
Note:Themachinewillshiftupwardatthe
lowerpinshippingbracket.
6.Removethefastenerssecuringtheshipping
bracketstothemachine.Removeanddiscard
theshippingbrackets.
9
