g300452
Figure77
1.Adjustmentbolt
7.Ensurethatthechainsaretautandtightenthe
bolts.
8.Checktheside-to-sidelevelandthefront-to-rear
pitch;refertoCheckingtheSide-to-SideLevel
(page48)andCheckingtheMowerDeck
Front-to-RearPitch(page49).
ReplacingtheGrass
Deector
ServiceInterval:Beforeeachuseordaily—Inspect
thegrassdeectorfordamage.
WARNING
Anuncovereddischargeopeningcouldallow
themachinetothrowobjectstowardyouor
bystanders,resultinginseriousinjury.Also,
contactwiththebladecouldoccur.
Neveroperatethemachineunlessyouinstall
amulchplate,dischargedeector,orgrass
collectionsystem.
1.Disengagethespringfromthenotchinthe
deectorbracketandslidetherodoutofthe
weldeddeckbrackets,spring,anddischarge
deector(Figure78).
g302010
Figure78
1.Rod4.Deckbrackets
2.Deector
5.Hairpincotter
3.Spring6.Springinstalledoverthe
rod
2.Removethedamagedorworndischarge
deector.
50
