Toro ProStripe 560 User Manual

decal134-3333
134-3333
1.Quick-washport
decal133-8062
133-8062
Setup
Important:Removeanddiscardtheprotective
plasticsheetthatcoverstheengine.
1
AssemblingtheHandle
Partsneededforthisprocedure:
2
Lowerhandlebar(left)
2
Lowerhandlebar(right)
2
Clampplate
2
Shortbolt
4Flatwasher
6Locknut
4
Cupwasher
4Longbolt
1Upperhandlebar
6
Cap
Procedure
WARNING
Assemblingthehandleimproperlycan
damagethecables,causinganunsafe
operatingcondition.
•Donotdamagethecableswhen
assemblingthehandle.
•Ensurethatthecablesareroutedtothe
insideofthehandleanddonotcatchthe
reardeector.
•Ifacableisdamaged,contactyour
AuthorizedServiceDealer.
1.Removethehexnutsfromthe2exposedbolts
onthetopofthedeck.
2.Installalowerhandlebartoeachsideofthe
topofthemowerdeckwithaclampplateand
thehexlocknutremovedfromthedeckinthe
previousstep(Figure3).
Note:Thelowerhandletubeshaveabend
alongthemidsection;ensurethatthetubesare
4
