ProcedureDescription
Qty.
Use
Hitchframe
1
Bolt(3/8x2inches)
2
Nut(3/8inch)
2
Capscrew(3/8x1-1/2inches)
2
Locknut(3/8inch)
2
Cylinderpin
2
Adapterplate1
Pusharmtube1
Pinassembly2
Thread-formingscrew
2
Bolt(5/8x1-1/2inches)
2
Washer(1.68-inchoutsidediameterx
0.65-inchinsidediameter)
2
Tube1
Clevispin
1
7
Cotterpin
1
Installthepusharmsandhitchframe.
45°hydraulicttingwithO-ring
1
Hydrauliccylinder1
90°hydraulicttingwithO-ring
1
Smallretainingring
1
Pin1
8
Largeretainingring2
Installthehydrauliccylinder.
Tubeassembly1
Hydraulichose(PartNo.108-8449)
1
Hydraulichose(PartNo.108-8453)
1
Hydraulichose(PartNo.108-8454)
1
Wirehoseholder1
Threadformingscrew(5/16x3/4inch)
2
9
Plasticcabletie3
Installthehydraulichoses(Model
08705).
Tubeassembly1
Hydraulichose(PartNo.108-8449)
1
Hydraulichose(PartNo.108-8453)
1
Hydraulichose(PartNo.108-8454)
1
Wirehoseholder1
Threadformingscrew(5/16x3/4inch)
2
10
Plasticcabletie3
Installthehydraulichoses(Model
08745).
Leverguideplate1
Flange-headscrew2
Washer2
Controlpaneldecal
1
Controlpanel
1
Knob1
11
Plasticcabletie3
Installthecontrolpanelandleverguide
plate.
12
Operator’sManual
1
Readthedocumentationandstoreitin
asafelocation.
