Toro Sand Pro 5040 - Preparing to Install Hydraulic Components

g003662
Figure3
1.Centershroud
3
PreparingtoInstallthe
HydraulicComponents
NoPartsRequired
Procedure
1.Locatethehydraulictubethatgoesfromtheoil
coolertotheexistingliftvalve(Figure4).
2.Removethefastenersandtubeclampsecuring
thehydraulictubestotheframe.
3.Disconnectandremovethehydraulictubefrom
theoilcoolerandtheliftvalve(Figure4and
Figure6).
Note:Youmaydiscardthishydraulictube.
Note:Tominimizeoillosswhenremoving
thehydraulictube,havethereplacementhose
readyorcapthettingonthecoolerusingoneof
theprotectiveshippingcapsremovedfromthe
tubeassembly,PartNo.108-8447(Figure19).
g003671
Figure4
1.Oilcooler
2.Hydraulictube
4.Securetheremaininghydraulictubetothe
framewiththeclampandfastenerspreviously
removed.
4
