Toro Sand Pro 5040 - Preparing the Machine; Removing the Shrouds

1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface.
2.Lowertheattachments.
3.Engagetheparkingbrake.
4.Shutofftheengineandremovethekey.
2
RemovingtheShrouds
NoPartsRequired
Procedure
1.Raisetherearofthemachineandpositionjacks
undertherearwheelmotormounts.
2.Removetherightreartire.
3.Removethe4washersandboltsmountingthe
controlpaneltotheconsole(Figure1).
4.Unplugthewirefromthehourmeter.
5.Removethecontrolpanel(Figure1).
6.Removethe3boltssecuringtheconsoletothe
frame(Figure1).Removetheconsolebygently
liftingthebottomedgeoftheconsolearound
thesupportbracketandslidingitupbeyondthe
brakehandle.
g003660
Figure1
1.Controlpanel3.Consolemountingbolt
locations
2.Console
7.Removethe4boltssecuringtherighthand
wheelshroudtotheframeandremovethe
shroud(Figure2).
g003661
Figure2
1.Righthandwheelshroud
8.Disconnectandremovethecentershroudfrom
theframe(Figure3).
