ThrottleLever
Thethrottlelevercontrolstheenginespeed.With
theleverreleased,intheDISENGAGEDposition,the
enginerunsatidle.Thisisalsothestartingposition.
Whenyoupullthelevertothehandle,theengine
speedincreases,thecentrifugalclutchengages,and
thecuttingwheelrotates.
g014874
Figure6
1.Throttlelever
2.Safetybail
ParkingBrake
Theparkingbrakeholdstheleftwheelfromturningto
securethemachineandforeasymovementofthe
machinefromsidetosidewhengrindingastump
(Figure7).
g243949
Figure7
1.Parkingbrake(engaged)
2.Parkingbrake
(disengaged)
ChokeLever
Usethechokelever(Figure3)tostartacoldengine.
Beforepullingtherecoil-starthandle,movethechoke
levertotheCLOSEDposition.Oncetheengineis
running,movethechokelevertotheOPENposition.
Donotusethechokeiftheengineisalreadywarmed
uporiftheairtemperatureishigh.
Recoil-StartHandle
Tostarttheengine,pulltherecoil-starthandle(Figure
3)quicklytoturntheengineover.RefertoStartingthe
Engine(page11)forthecorrectstartingprocedure.
Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
CuttingDepth30cm(12inches)
Length
127cm(50inches)
Width
56cm(22inches)
Height
107cm(42inches)
Weight
47kg(103lb)
Attachments/Accessories
AselectionofT oroapprovedattachmentsand
accessoriesisavailableforusewiththemachine
toenhanceandexpanditscapabilities.Contact
yourAuthorizedServiceDealerorauthorizedToro
distributororgotowww.T oro.comforalistofall
approvedattachmentsandaccessories.
Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineT oro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.
