Toro TimeCutter MX 3450 - Positioning the Seat; Adjusting the Anti-Scalp Rollers; Adjusting the Motion-Control Levers

PositioningtheSeat
Positiontheseatwhereyouhavethebestcontrolofthe
machineandaremostcomfortable(Figure19).
Figure19
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheight-of-cut,adjusttheheight
oftheanti-scalprollers.
Note:Adjusttheanti-scalprollerssotherollersdonottouch
thegroundinnormal,atmowingareas.
1.Disengagethebladecontrolswitch(PTO),movethe
motioncontrolleverstotheneutrallockpositionand
settheparkingbrake.
2.Stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
3.Adjusttheanti-scalprollersasshowninFigure20to
matchtheclosestheight-of-cutposition.
G010233
1
2
3
4
Figure20
1.Anti-scalproller3.Flangenut
2.Bolt4.Holespacing
AdjustingtheMotion-Control
Levers
AdjustingtheHeight
Youcanadjustthemotion-controllevershigherorlowerfor
maximumcomfort(Figure21).
g027252
B
A
Figure21
AdjustingtheTilt
Youcanadjustthemotion-controlleversforwardorrearward
foryourcomfort.
1.Loosentheupperboltholdingthecontrollevertothe
control-armshaft.
2.Loosenthelowerboltjustenoughtopivotthecontrol
leverforwardorrearward(Figure21).
3.Tightenbothboltstosecurethecontrolleverinthe
newposition.
4.Repeattheadjustmentfortheothercontrollever.
21
