Toro TimeCutter MX 4200 Setup Instructions

1
ConnectingtheBattery
NoPartsRequired
Procedure
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
1.Locatethebatteryandnegativebatterycable.
2.Removetheplasticcapfromthenegativebatterypost.
3.Removethefastenersonthenegativebatterycable,
andusethemtosecurethenegativebatterycableto
thenegativebatterypost(Figure1).
G018395
2
1
4
3
6
5
Figure1
1.Negativebatterycable4.Negativebatterypostcap
2.Wingnut
5.Carriagebolt
3.Washer6.Negativebatterypost
2
InstallingtheRearHitch
Partsneededforthisprocedure:
1Rearhitch
2
Bolt(5/16x1inch)
2
Locknut(5/16inch)
Procedure
InstallthebrackettotheframeasshowninFigure2and
Figure3.
g015397
1
2
Figure2
Beforeassembly
1.Bolts2.Locknuts
Figure3
Afterassembly
2
