Toro TimeCutter MX 6050 - Replacing the Grass Deflector

g017618
Figure73
1.Rodandspringassembly
installed
3.Rod,shortend,moved
behindmowerbracket
2.Loopendofthespring
installedintothenotchin
thedeectorbracket
4.Shortend,retainedby
mowerbracket.
7.Securetherodandspringassemblybytwisting
itsotheshortendoftherodisplacedbehind
thefrontbracketweldedtothedeck(Figure73).
Important:Thegrassdeectormustbe
springloadedinthedownposition.Liftthe
deectoruptotestthatitsnapstothefull
downposition.
ReplacingtheGrass
Deector
MachineswithStampedMower
DecksOnly
WARNING
Anuncovereddischargeopeningcouldallow
themachinetothrowobjectstowardyouor
bystanders,resultinginseriousinjury.Also,
contactwiththebladecouldoccur.
Neveroperatethemachinewithoutthe
grassdeector,thedischargecover,orthe
grass-collectionsysteminplace.
Inspectthegrassdeectorfordamagebeforeeach
use.Replaceanydamagedpartsbeforeuse.
1.Removethenut(3/8inch)fromtherodunder
themower(Figure74).
g005192
Figure74
1.Mowerdeck
5.Spring
2.Grassdeector
6.Nut(3/8inch)
3.Grass-deectorbracket7.Shortstandoff
4.Rod
2.Slidetherodoutoftheshortstandoff,thespring,
andthegrassdeector(Figure74).
3.Removethedamagedorworngrassdeector.
4.Replacethegrassdeector(Figure74).
5.Slidetherod(straightend),throughthe
rear-grass-deectorbracket.
6.Placethespringontherod,withtheendwires
downandbetweenthegrassdeectorbrackets.
7.Sliderodthroughthesecondgrass-deector
bracket(Figure74).
8.Inserttherodatthefrontofthegrassdeector
intotheshortstandoffonthedeck.
9.Securetherearendoftherodintothemower
withanut(3/8inch)asshowninFigure74.
Important:Thegrassdeectormustbe
springloadedandinthedownposition.Lift
thedeectoruptotestthatitsnapstothe
fulldownposition.
