Toro TimeCutter SW Series - Connecting the Battery

ProcedureDescription
Qty.
Use
7
Nopartsrequired
–
Checkthemoweradjustment.
Ignitionkey1
Hosecoupling(notincludedwithCE
models)
1
Operator'sManual
1
EngineOwner’sManual(non-Toro
engines)
1
8
KeyChoice®key(blue)
1
Completethesetup.
1
ConnectingtheBattery
NoPartsRequired
Procedure
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandlead
compounds,chemicalsknownto
theStateofCaliforniatocause
cancerandreproductiveharm.Wash
handsafterhandling.
1.Locatethebatteryandnegativebatterycable.
2.Removetheplasticcapfromthenegative
batterypost.
3.Removethefastenersonthenegativebattery
cable,andusethemtosecurethenegative
batterycabletothenegativebatterypost(Figure
1).
G018395
2
1
4
3
6
5
g018395
Figure1
1.Negativebatterycable4.Negativebatterypostcap
2.Wingnut
5.Carriagebolt
3.Washer6.Negativebatterypost
2
