Toro TimeCutter SW Series User Manual

g027695
g027695
Figure9
3.Routethewireharnesstotherightsideofthe
machineandpushtheplasticconnectorintothe
seatframehole(Figure10).
g028383
1 2
g028383
Figure10
1.Plasticconnectorinseat
framehole
2.Wireharness
6
InstallingtheGrass
Deector
Partsneededforthisprocedure:
1
Grassdeector(ifnotinstalled)
Procedure
Ifthegrassdeectorisnotinstalled,removeitfrom
thepackagingandinstallitontothemowerdeck.
RefertoyourOperator’sManualforthecorrect
proceduretoinstallthegrassdeector.
7
CheckingtheMower
Adjustment
NoPartsRequired
Procedure
Adjusttheside-to-sidelevelandthefront-to-rearblade
slope.UsetherelevantproceduresintheOperator's
Manualtoverifythatthedeckislevel,andmakeany
adjustmentsasnecessary.RefertotheOperator's
Manualformoreinformation.
