2
InstallingtheRearHitch
Partsneededforthisprocedure:
1Rearhitch
2
Bolt(5/16x1inch)
2
Locknut(5/16inch)
Procedure
1.Installthebrackettotheframeasshownin
Figure2.
2.Torquetheboltsbetween19.8and25.4N∙m
(175and225in-lb).
g028437
Figure2
1.Bolt(2)2.Locknut(2)
3
InstallingtheSteering
Wheel
Partsneededforthisprocedure:
1
Steeringwheel
1Topcover
1Locknut
1Rearcover
2
Screws
Procedure
1.Rotatethesteeringcolumnuptotheuser
position(Figure3).
g027703
Figure3
2.PositionthesteeringwheelasshowninFigure5.
3.Installthesteeringwheelandtopcovertothe
steeringcolumnwiththelocknut(Figure4).
4.Torquethelocknutbetween36.6and44.7N∙m
(27and33ft-lb).
5.Installthesteering-wheelcover.
