4
InstallingtheGuard
Partsneededforthisprocedure:
1
Guard
Procedure
1.UsingtheprovidedAllenwrench,removethe2socketheadscrews,2washers,and2spacersfromthe
trimmerbase(AofFigure6).
2.Aligntheguardontothetrimmerbase(BofFigure6).
3.Securetheguardontothebaseofthetrimmerwiththe2socketheadscrews,2washers,and2spacers
previouslyremoved(CofFigure5).
g273281
Figure6
10
