3
InstallingtheAuxiliaryHandle
Partsneededforthisprocedure:
1Auxiliaryhandleassembly
Procedure
1.Separatetheauxiliaryhandlefromthehandleplatebyremovingthe4socketheadscrewsusingthe
providedAllenwrench(AofFigure5).
2.Lineuptheauxiliaryhandlewithauxiliaryhandleplateonthetrimmerhandle(BofFigure5).
3.Securetheauxiliaryhandletothehandleplatewiththe4socketheadscrewspreviouslyremoved(Cof
Figure5).
g273280
Figure5
9
