Toro TimeMaster 21199 - Unfolding the Handle

2
UnfoldingtheHandle
Partsneededforthisprocedure:
1Allenwrench
Procedure
1.Unfoldthehandle(AofFigure4).
2.Alignthelockingbuttononthelowershaftwiththeslottedholeontheuppershaftandslidethe2shafts
together(BandCofFigure4).
Note:Thelockingbuttonclicksintotheslottedholewhentheshaftsaresecured(DofFigure4).
3.UsingtheprovidedAllenwrench,tightenthescrewontheshaftconnectoruntilitissecure(EofFigure4).
g280969
Figure4
