CheckingtheSideDischarge
Chute
NoPartsRequired
Procedure
Ifthereareplastictiesholdingthesidedischargechute
up,removethemandlowerthechuteintoplace.
WARNING
Anuncovereddischargeopeningcouldallowthe
lawnmowertothrowobjectsintheoperator’sor
bystander’sdirectionandresultinseriousinjuryor
death.Also,contactwiththebladecouldoccur.
Neveroperatethelawnmowerwiththegrass
deectorremovedunlessyouinstallacoverplate,a
mulchplate,oragrasschuteandcatcher.
1.MakesuretheLendofspringisinstalledbehind
thedeckedgebeforeinstallingtheboltasshownin
Figure9.
2.PlacetheJhookendofspringaroundgrassdeector
(
Figure9).
Important:Thegrassdeectormustbefreeto
rotatewithdownwardtension.Liftthedeector
uptothefullopenpositionandensurethatit
rotatesfreely,withoutbindingintothefulldown
position.
Figure9
1.GrassDeector4.Lendofspring,place
behinddeckedgebefore
installingbolt
2.Spring
5.Deckedge
3.Jhookendofspring
