G013506
1
2 3
Figure5
1.Locknut(1/2inch)3.Bolt(1/2x3-1/4inch)
2.ROPS
7
CheckingtheMachinefor
Grease
Partsneededforthisprocedure:
1tube
Number2generalpurposelithiumbaseor
molybdenumbasegrease.(Purchaseseparately.)
Procedure
1.Checkthegreaseforthethreespindlebearingsand
theidlerpulley.Ifneeded,addgreaseuntilitcomes
outofthelowerseals.
G009029
Figure6
2.Checkthegreaseforthepumpdrivebeltidlerarm.
Figure7
3.Checkthegreaseinthecasterpivotsandcaster
wheelbearings(
Figure8).
Figure8
4
