LOOSELY
ASSEMBLE BUMPERS
TO THE HANDLES AS SHOWN USING
FLANGE SPACERS, BOLTS AND LOCK
WASHERS FROM PREVIOUS STEP
14
15
12
4
7
6
REPEAT THIS STEP, ONE AT A TIME
FOR REMAINING 3 BUMPERS. KEEP
BOLTS LOOSE UNTIL ALL BUMPERS
ARE ASSEMBLED
17
XTBK
TANK BUMPER KIT (OPTIONAL)
NOTE:
Once all bumpers have been assembled,
SECURELY
tighten all
bolt connections.
To Next Page
