Torque TANK - Table of Contents; 55726 Pa Ptd Assy, Right Push Handle (Optional); 55724 Pa Ptd Assy, Left Push Handle (Optional); 5572101 Wldmt, Hor Push Handle (Optional)

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
TABLE OF CONTENTS:
TANK ASSEMBLY: PAGES 3 - 5
TANK CHAIN ADJUSTMENT: PAGES 6 - 9 & 11 - 13
TANK BELT ADJUSTMENT: PAGES 6 - 8 & 10 - 13
TANK WEIGHT HORN KIT (OPTIONAL): PAGES 14 - 15
TANK BUMPER KIT (OPTIONAL): PAGES 16 - 17
INSPECTION & LUBRICATION: PAGE 18
NOTICES: PAGE 19
ITEM PART NUMBER DESCRIPTION QTY
1 5585401 ASSY, TWO BRAKE FRAME 1
2 5619001 WHEEL, 12" DIA X 3.5 WIDE 4
3 2011201 WASHER, STEEL 12.7 ID-40 OD-4 THK CLEAR ZINC 4
4 2010901 WASHER, M12 SPLIT LOCK 12
5 2011301 SCREW, M12-1.75 X 30L SOC HD GR 12.9 CLEAR ZINC 4
6 55726PA PTD ASSY, RIGHT PUSH HANDLE (OPTIONAL) 2
7 55724PA PTD ASSY, LEFT PUSH HANDLE (OPTIONAL) 2
8 5572101 WLDMT, HOR PUSH HANDLE (OPTIONAL) 2
9 2010501 WASHER, STEEL 10.5 ID-20 OD-2 THK CLEAR ZINC 4
10 2012801 SCREW, M10-1.5 X 25L SOC HD GR 12.9 CLEAR ZINC 4
11 2010801 WASHER, STEEL 12.7 ID-25 OD-2 THK CLEAR ZINC 8
12 2010701 SCREW, M12-1.75 X 85L SOC HD GR 12.9 CLEAR ZINC 8
13 56024PA PTD ASSY, TANK WEIGHT HORN 2
14 5433701 SPACER, FLANGE (OPTIONAL) 8
15 5602701 BUMPER, TANK (OPTIONAL) 4
2
