1. LOOSEN FOUR
BOLTS (CIRCLED)
3. RETIGHTEN
FOUR BOLTS
(CIRCLED)
CHAIN
2. TURN BOLT CLOCKWISE TO
TIGHTEN CHAIN,
TURN BOLT COUNTER CLOCKWISE
TO LOOSEN CHAIN
CHAIN ADJUSTMENT
9
NOTE:
The chain tension on TANK is pre-set at the factory. However, if the
chain becomes too loose or is too tight, then please follow the steps
in numbered numbered order to adjust.
