The automatic rmware update method is the primary option when updating
the T-1. However there may be some circumstances that a manual update
is required. This process details manual updates.
▌ MANUAL UPDATING OF FIRMWARE
1. Connect T-1 to a PC or Mac hosting the T-1 Cong tool using the USB
cable and connections.
2. Remove all other connections such as MIDI, CV etc. Only the USB
should be connected.
3. Open the Torso ‘T-1 Cong’ Tool.
4. Select from the T-1 Cong Header Menu, ‘Tools’ > ‘Upload Firmware’ >
‘Factory Version’.
5. Do not unplug or power down during rmware update.
6. The port will be automatically connected but if not the manual option will
be presented. Names on the lines of:-
• MacOS - ‘dev/tty.usbmodemXXXXX’.
• Windows - ‘Comxx’ - use baud rate 115200 or 460800?”:|{}=The
latest rmware will be uploaded to the T-1 which will take about 2
minutes. T1- will restart ready for use.
10.3 User Interface Options
A number of user experience options are congurable. This includes
brightness, CTRL button behaviour and the ability to change the default
knob turn visualisation. These can easily be edited using the T-1 Cong tool
in the ‘Misc’ page options when USB connected from a PC/Mac to the T-1.
▌ ADJUSTING BUTTON BRIGHTNESS
1. Open the Torso ‘T-1 Cong’ Tool. Open the ‘Misc’ page by mouse
clicking in the top left menu options.
2. Use Mouse Click and hold to drag the ‘LED Brightness’ slider setting.
3. The range is 0-100% for the RBG button brightness and can be set to a
user preference. Default is 75%. The setting will be stored in T-1.
4. Brightness change can also be performed on the hardware. Hold
[CTRL] + Turn (TEMPO) to adjust the brightness.
▌ CHANGING CTRL BUTTON BEHAVIOUR
1. Open the Torso ‘T-1 Cong’ Tool. Open the ‘Misc’ page by mouse
clicking in the top left menu options.
2. Mouse Click the button to toggle ‘Hold [CTRL] on Double Tap’.
• The ‘ON’ position will allow double tapping of the [CTRL] button to
lock its status to on.
• The ‘OFF’ position is default and will always need [CTRL] to be held
when accessing secondary functions.
▌ CHANGING PARAMETER KNOB QUICK VIEW
1. Open the Torso ‘T-1 Cong’ Tool. Open the ‘Misc’ page by mouse
clicking in the top left menu options.
2. Mouse Click the button to toggle ‘Quick View’.
• The ‘ON’ position will allow the value buttons to be temporarily
displayed with the status setting when a knob is turned.
• The ‘OFF’ position will not display the value buttons when turning a
(Knob). Using Press & Turn (Knob) will visualise the button state.
