8
The T-1 Notebook : Reference & Guide
9
The T-1 Notebook : Reference & Guide
T-1 is an algorithmic sequencer and does not, in itself generate any audio.
3.5mm Mini Jack TR Mono
connections for 4 x CV - Control
Voltage and 2 x Gate outputs.
3.5mm Mini Jack connections for
external clock synchronisation
inputs / outputs.
Supply is via the USB-C
Also MIDI via USB.
(cable supplied)
All dimensions include enclosure plus the control knobs, buttons and rubber feet. Weight is 815 grams (1,8 lbs).
T-1 is supplied along with a USB-C to USB-A cable and a 3.5mm to MIDI adapter.
3.5mm Mini Jack CV - Control
Voltage modulation input.
MIDI In, Out, Thru using a 3.5mm
Jack to 5 Pin MIDI adapter type A.
(supplied)
1.4 Hardware Overview
304 mm
11,9 Inch
114 mm
4,5 Inch
39 mm
1,5 Inch
1.3 Power Up
T-1 Sequencer is powered using the USB-C connection located at the rear
of the unit. There is no power switch and T-1 will power on immediately
when power is applied. T-1 requires a minimum of 390mA with 100%
brightness but will operate from 200mA upwards. The T-1 Default
brightness setting is 75% which is adjustable. A 500mA minimum power
source is recommended.
▌ POWERING ON / OFF THE T-1 SEQUENCER
1. Connect the supplied USB-C cable between T-1 Sequencer and a USB
supply. This could be:-
• A portable USB power bank.
• USB Mains supply adapter.
• A powered USB hub.
• A PC or Macbook.
• A tablet or mobile device.
• Another powered device such as an instrument or synth.
2. T-1 will start up and the pads will illuminate ORANGE ⬛.
3. To power the unit off, disconnect the USB-C cable or the supply.
NOTES
USB
PC / Mac
T-1
USB Adapter
