Toshiba DIGITAL Series - Appendix C: Supported File Formats for USB Mode; Appendix D: PIN Information

English - 42 -
English
Appendix C: Supported File Formats for USB Mode
Media
File
Extension
Format
Remarks
Video Audio
(
Maximum resolution/Bitrate etc.
)
Music .mp3 -
MPEG 1/2
Layer 1/ 2/
3 (MP3)
Sample Rate: 8k ~ 48kHz,
Bitrate: 128kbps~320kbps
Photo .jpg
Baseline
JPEG
WxH = 15360x8640
Progressive
JPEG
WxH = 1024x768
Appendix D: PIN Information
Before connecting any external equipment, turn off all main power switches. If there is no switch, remove the
mains plug from the wall socket.
Signal information for Mini D-sub 15 pin connector
Pin No. Signal name Pin No. Signal name Pin No. Signal name
1 R 6 Ground 11 NC
2 G 7 Ground 12 NC
3 B 8 Ground 13 H-sync
4 NC* 9 NC 14 V-sync
5 NC 10 Ground 15 NC
* NC = not connected
