Toshiba DVR80KF - Page 117

2-4-8 N25E1AVDA
[27]
[31]
(C-3)
[26]
(C-4)
[25]
(C-2)
[28]
[29]
[30]
(C-5)
(S-9)
[24]
[23]
(L-7)
(L-8)
Fig. DM13H-1
[25a]
(S-9a)
[27]
[27]
[26]
To p Vi ew
First tooth on [47]
First groove on [27]
Align [26] and [27] as shown.
Pin of [36]
Pin of [33]
Position of Mode Lever when installed
Pin of [37]
Bottom View
Installation of [26]
When reassembling [27],
meet the first groove on
[27] to the first tooth on
[47] as shown.
Fig. DM13H-2
[32]
(L-9)
(P-5)
[34]
[35]
Refer to the Alignment
Section, Page 2-5-1.
[33]
Fig. DM14H
