7.11 Grease List
The parts used for the maintenance of this equipment are as follows.
*
Part list <P-I> represent
s the page item in “e-STUDIO5540C/6540
C/6550C, e-STUDIO5560C/
6560C/6570C Service Parts List”.
7.12 Operational Items in Overhauling (e-STUDIO5540C/6540C/
6550C only)
Overhauling must be performed in order to maintain the quality level of this equipment at the following
timing.
e-STUDIO5540C: When the number of output pages has reached 900,000 or 2.5 years have
passed from the start of use (Whichever is earlier.)
e-STUDIO6540C: When the number of output pages has reached 1,000,000 or 2.5 years have
passed from the start of use (Whichever is earlier.)
e-STUDIO6550C: When the number of output pages has reached 1,100,000 or 2.5 years have
passed from the start of use (Whichever is earlier.)
(1) Replace all the PM parts.
(2) Check the components in the drive section (gears, pulleys, timing belts, etc.). Replace them with
new ones if they are damaged.
(3) Check all the adhesives such as tape and Mylar if they are damaged or have become unstuck.
Replace them with new ones if necessary.
(4) Check the performance of all the switches and sensors. Replace them with new ones if
necessary.
(5) Clean inside the equipment thoroughly.
Symbol Grease name Volume Container
Parts list
<P-I>*
L Launa 40 100 cc Oiler 201-21
W1 White grease (Molykote EM-30L) 100 g Tube 201-24
W2 White grease (Molykote HP-300) 10 g Bottle 201-22
AV Alvania No.2 100 g Tube 201-23
FL Floil (GE-334C) 20 g Bottle
