8
© 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
ERROR CODE and TROUBLESHOOTING
8 - 99
[ED12] Shutter home position error
[ED13] Front alignment plate home position error
Classification Error item
Finisher jam The shutter is not at the home position. [MJ-1103/1104]
Check item Measures
Shutter • Open and close the shutter. If there is any mechanical
problem, fix its mechanism.
Shutter opening/closing sensor (S4) • Rotate sideways adjustment motor and fix its mechanism
if it does not rotate smoothly.
• Motor check
• Connector check
• Harness check
Shutter clutch (CLT1) • Clutch check
• Connector check
• Harness check
Finisher controller board • Connector check
• Board check
Replace parts Remarks
Shutter opening/closing sensor (S4)
Shutter clutch (CLT1)
Finisher controller board
Classification Error item
Finisher jam The front alignment plate is not at the home position. [MJ-
1103/1104]
Check item Measures
Front alignment plate • Move the front alignment plate. If there is any mechanical
problem, fix its mechanism.
Front alignment plate home position
sensor (S7)
• Sensor check
• Connector check
• Harness check
Front alignment motor (M9) • Motor check
• Connector check
• Harness check
Finisher controller board • Connector check
• Board check
Replace parts Remarks
Front alignment plate home position
sensor (S7)
Front alignment motor (M9)
Finisher controller board
To Next Page
