Toshiba E-studio5540c Service Manual

e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 98
[ED10] Skew adjustment motor (M1) home position detection abnormality
[ED11] Sideways adjustment motor (M2) home position detection error
Classification Error item
Finisher jam The Skew adjustment motor is not at the home position. [MJ-
1103/1104 (when MJ-6102 is installed)]
Check item Measures
Finisher • Check if there is any paper in the finisher. Remove it if
there is.
Skew adjustment motor (M1) • Motor check
• Connector check
• Harness check
Skew HP sensor (S2) • Sensor check
• Connector check
• Harness check
Punch controller board • Connector check
• Board check
Replace parts Remarks
Skew adjustment motor (M1)
Skew HP sensor (S2)
Punch controller board
Classification Error item
Finisher jam The Sideways adjustment motor is not at the home position.
[MJ-1103/1104 (when MJ-6102 is installed)]
Check item Measures
Finisher • Check if there is any paper in the finisher. Remove it if
there is.
Sideways adjustment motor (M2) • Rotate sideways adjustment motor and fix its mechanism
if it does not rotate smoothly.
• Motor check
• Connector check
• Harness check
Sideways deviation HP sensor (S3) • Sensor check
• Connector check
• Harness check
Punch controller board • Connector check
• Board check
Replace parts Remarks
Sideways adjustment motor (M2)
Sideways deviation HP sensor (S3
Punch controller board
