e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 12
ED14 Finisher jam
(Finisher section)
Rear alignment plate home position error:
The rear alignment plate is not at the home
position. [MJ-1103/1104]
P. 8-100
ED15 Paddle home position error P. 8-100
ED16 Buffer tray home position error P. 8-100
EF10 Finisher jam
(Saddle section)
Paper not supported for Saddle Stitch
Finisher: Unsupported paper size, type and
an excess number of pages for stapling are
selected.
P. 8-101
EF11 Saddle Stitch Finisher stapling error (front):
Front stapling is not correctly done.
P. 8-101
EF12 Saddle Stitch Finisher stapling error (rear):
Rear stapling is not correctly done.
P. 8-102
EF13 Saddle paper holder home position
detection abnormality: The paper holder
home position cannot be detected.
P. 8-102
EF14 Saddle paper exit jam: Outputting paper is
not completed within a fixed time.
P. 8-103
EF15 Saddle Stitch Finisher side alignment motor
home position detection abnormality: The
side alignment motor home position cannot
be detected.
P. 8-103
EF16 Saddle Stitch Finisher stacker motor home
position detection abnormality: The stacker
motor home position cannot be detected.
P. 8-104
EF17 Saddle Stitch Finisher folding blade home
position detection abnormality: The folding
blade home position cannot be detected.
P. 8-104
EF18 Saddle Stitch Finisher additional folding
roller home position detection abnormality:
The additional folding roller home position
cannot be detected.
P. 8-104
EF19 Saddle paper folding jam: Fold processed
paper cannot be transported to the
additional folding roller.
P. 8-105
EF20 Saddle stacker jam: Transported paper
cannot be detected in the stacker.
P. 8-105
EF21 Hole Punch Unit paper leading edge skew
detection abnormality: One of the 2 skew
sensors cannot detect the paper within a
fixed time.
P. 8-106
EF22 Hole Punch Unit paper leading edge
detection abnormality: The paper leading
edge cannot be detected within a fixed time
after its skew is found.
P. 8-107
EF23 Hole Punch Unit paper alignment
abnormality: The paper position cannot be
detected due to the sideway registration
mechanism.
P. 8-107
EF24 Hole Punch Unit paper trailing edge skew
detection abnormality: One of the 2 skew
sensors cannot detect the paper within a
fixed time.
P. 8-108
Error code Classification Contents Troubleshooting
