Toshiba H3BG2L100C61T - Appendix D: Battery Backup Tables (Internal & External Battery Cabinets)

D11600XPi Series UPS Installation and Operation Manual – 60616-014
Appendix D: Battery Backup Tables (Internal & External Battery Cabinets)
3.6kVA – H3BG2L036C61T
(Runtimes are approximate)
UPS ESTIMATED RUNTIME WITH ONLY INTERNAL BATTERIES @ .85pf
Rating PF Output
Voltage
Rated I Rated
Load %
Output
Watts
# Batt # Strings Nominal Runtime
3.6 0.85 240 15.00 0.10 306 12 1 144 72
3.6 0.85 240 15.00 0.20 612 12 1 144 48
3.6 0.85 240 15.00 0.30 918 12 1 144 33
3.6 0.85 240 15.00 0.40 1224 12 1 144 23
3.6 0.85 240 15.00 0.50 1530 12 1 144 18
3.6 0.85 240 15.00 0.60 1836 12 1 144 14
3.6 0.85 240 15.00 0.70 2142 12 1 144 12
3.6 0.85 240 15.00 0.80 2448 12 1 144 10
3.6 0.85 240 15.00 0.90 2754 12 1 144 9
3.6 0.85 240 15.00 1.00 3060 12 1 144 7
UPS ESTIMATED RUNTIME WITH INTERNAL BATTERIES AND 1 MATCHING BATTERY CABINET @ .85pf
Rating PF Output
Voltage
Rated I Rated
Load %
Output
Watts
# Batt # Strings Nominal Runtime
3.6 0.85 240 15.00 0.10 306 12 4 144 240
3.6 0.85 240 15.00 0.20 612 12 4 144 150
3.6 0.85 240 15.00 0.30 918 12 4 144 112
3.6 0.85 240 15.00 0.40 1224 12 4 144 98
3.6 0.85 240 15.00 0.50 1530 12 4 144 82
3.6 0.85 240 15.00 0.60 1836 12 4 144 70
3.6 0.85 240 15.00 0.70 2142 12 4 144 60
3.6 0.85 240 15.00 0.80 2448 12 4 144 55
3.6 0.85 240 15.00 0.90 2754 12 4 144 50
3.6 0.85 240 15.00 1.00 3060 12 4 144 45
UPS ESTIMATED RUNTIME WITH INTERNAL BATTERIES AND 2 MATCHING BATTERY CABINETS @ .85pf
Rating PF Output
Voltage
Rated I Rated
Load %
Output
Watts
# Batt # Strings Nominal Runtime
3.6 0.85 240 15.00 0.10 306 12 7 144 300
3.6 0.85 240 15.00 0.20 612 12 7 144 240
3.6 0.85 240 15.00 0.30 918 12 7 144 180
3.6 0.85 240 15.00 0.40 1224 12 7 144 150
3.6 0.85 240 15.00 0.50 1530 12 7 144 120
3.6 0.85 240 15.00 0.60 1836 12 7 144 112
3.6 0.85 240 15.00 0.70 2142 12 7 144 98
3.6 0.85 240 15.00 0.80 2448 12 7 144 90
3.6 0.85 240 15.00 0.90 2754 12 7 144 82
3.6 0.85 240 15.00 1.00 3060 12 7 144 72
