14-3. Sensor Characteristics
14-3-1. Outdoor Unit
n Temperature sensor characteristics
-10
10
0
20
30
40
0 10 20 30 40 50 60 70
Characteristic-2
Temperature [ C]
Outdoor TS1, TO, TL sensors
Resistance [kΩ]
50
0
100
150
200
0
5
10
10 20 30 40 50 60 100 110 120 130 140 150
Characteristic-4
Temperature [ C]
Outdoor TD1, TD2, TK1, TK2,
TK3, TK4 sensors
Resistance [kΩ]
Resistance [kΩ]
(65 C or higher)
50
0
100
150
200
5
0
10
15
20
-20-30 -10 0 10 20 30 40 50 60 70 80 90 100
Characteristic-5
Temperature [ C]
Outdoor TE1 sensor
Resistance [kΩ] (10 C or lower)
Resistance [kΩ]
(10 C or higher)
