User’s Manual 1-11
Introduction
Communications
Headphone(S/P DIF)
jack
This jack outputs analog audio signals. This jack
can be used also as S/P DIF jack and enables
connection of optical digital correspondence
apparatus.
Microphone Jack A 3.5 mm mini microphone jack enables
connection of a three-conductor mini jack for
monaural microphone input.
Modem Where present, it provides capability for data and
fax communication. It supports V.90 (V.92). The
speed of data transfer and fax communication
depends on the analog telephone line conditions.
The computer has a modem jack for connection
to a telephone line. Both V.90 and V.92 are
supported only in the USA, Canada, Australia.
V.90 is available in other regions.
(Provided with some models)
LAN The computer is equipped with a LAN card that
supports Fast Ethernet LAN (100 Mbit/s,
100BASE-TX) or Gigabit Ethernet LAN (1 Gbit/s,
1000BASE-T). It is preinstalled as a standard
device in some markets.
(depending on model you purchased)
Wireless LAN Where present, it supports the A,B,G and draft N
standards but it is compatible with other LAN
systems based on Direct Sequence Spread
Spectrum / Orthogonal Frequency Division
Multiplexing radio technology that complies with
the IEEE 802.11 Standard.
■ Automatic Transmit Rate Select mechanism
in the transmit range of 54, 48, 36, 24, 18, 12,
9 and 6 Mbit/s. (IEEE 802.11a/g)
■ Automatic Transmit Rate Select mechanism in
the transmit range of 11, 5.5, 2 and 1 Mbit/s.
(IEEE 802.11b)
■ Roaming over multiple channels
■ Card Power Management
■ Wired Equivalent Privacy (WEP) data
encryption, based on 128 bit encryption
algorithm.
■ Advanced Encryption Standard (AES) data
encryption, based on 128 bit encryption
algorithm.
