2. SPECIFICATIONS
Unit model Indoor
RAS-B05J2KVG-E
RAS-B07J2KVG-E
Outdoor
RAS-05J2AVG-E
RAS-07J2AVG-E
Cooling capacity (kW)
Cooling capacity range (kW) 0.76-2.60
Heating capacity (kW) 2.50
Heating capacity range (kW)
Power supply
1Ph/50Hz/220-240V
Electric Indoor Operation mode Cooling Heating Cooling Heating
characteristic Running current (A) 0.19-0.17 0.19-0.17 0.22-0.20 0.22-0.20
Power consumption (W) 25 25 30 30
Power factor (%) 60 60 62 62
Outdoor Operation mode Cooling Heating Cooling Heating
Running current (A) 1.81-1.67 2.26-2.08 2.48-2.30 3.08-2.82
Power consumption (W) 345 445 500 610
Power factor (%) 87 90 89 91
Starting current (A)
COP (Cooling / Heating) 4.05/4.26 3.77/3.91
Operating Indoor High (Cooling / Heating) (dB-A) 37/37 38/38
noise Medium (Cooling / Heating) (dB-A) 30/30 31/31
Low (Cooling / Heating) (dB-A) 22/22 23/23
Outdoor (Cooling / Heating) (dB-A) 46/48 46/48
Indoor unit Unit model
RAS-B05J2KVG-E RAS-B07J2KVG-E
Dimension Height (mm) 293 293
Width (mm) 798 798
Depth (mm) 230 230
Net weight (kg) 9 9
Fan motor output (W) 25 25
Air flow rate (Cooling / Heating)
(m
3
/ min)
8.5/8.7 8.7/8.9
Outdoor unit Unit model
RAS-05J2AVG-E RAS-07J2AVG-E
Dimension Height (mm) 530 530
Width (mm) 660 660
Depth (mm) 240 240
Net weight (kg) 22 22
Compressor Motor output (W) 550 550
Type
Model KSK75D43UEZA
Fan motor output (W) 43
Air flow rate (Cooling / Heating)
(m
3
/ min)
30/30 30/30
Piping Type Flare connection
connection Indoor unit Liquid side (mm)
6.35 6.35
Gas side (mm)
9.52 9.52
Outdoor unit Liquid side (mm)
6.35 6.35
Gas side (mm)
9.52 9.52
Maximum length (m) 15 15
Maximum charge-less length (m) 15 15
Maximum height difference (m) 12 12
Refrigerant Name of refrigerant R32 R32
Weight (kg) 0.40 0.40
Wiring Power supply 3 Wires: Includes earth (Outdoor)
connection Interconnection 4 Wires: Includes earth
Usable temperature range Indoor (Cooling / Heating)
(
o
C)
21-32/ -28 21-32/ -28
Outdoor (Cooling / Heating)
(C)
-15,46/-15,24
-15,46/-15,24
3.14
0.90-3.00
0.75-2.00
2.00
1.50 2.00
0.92-3.30
1.92 2.35 2.65
2-1. Specification
Single rotary type with DC-inverter variable speed control
KSK75D43UEZA
* The specification may be subject to change without notice for purpose of improvement.
Accessory Indoor unit
Installation plate
1
Wireless remote controller
1
Batteries 2
Remote controller holder
1
Active Carbon Catechin filter
-
Mounting screw
6(4x25L)
Remote controller holder
Flat head wood screw
Installation manual 1
Owner's manual
1
2(3.1x16L)
FILE NO. SVM-19001
- 6 -
