Toshiba RAS-B05J2KVG-E Service Manual

Unit model Indoor
RAS -B16J2KVG-E
Outdoor
RAS -16J2AVG-E
Cooling capacity (kW)
Cooling capacity range (kW)
Heating capacity (kW)
Heating capacity range (kW)
Power supply
1Ph/50Hz/220-240V
Electric Indoor Operation mode Co o ling H ea ting
characteristic Running current (A) 0.31-0.29 0.31-0.29
Power consumption (W) 45 45
Power factor (%) 65 65
Outdoor Operation mode Cooling Heating
Running current (A) 6.34-5.81 6.39-5.86
Power consumption (W) 1355 1355
Power factor (%) 97 96
Starting current (A)
COP (Cooling / Heating) 3.00/3.57
Operating Indoor High (Cooling / Heating) (dB-A) 43/43
noise Medium (Cooling / Heating) (dB-A) 35/35
Low (Cooling / Heating) (dB-A) 25/25
Outdoor (Cooling / Heating) (dB-A) 49/51
Indoor unit Unit model
RAS -B16J2KVG-E
Dimension Height (mm) 293
Width (mm) 798
Depth (mm) 230
Net weight (kg) 10
Fan motor output (W) 35
Air flow rate (Cooling / Heating)
(m
3
/ min)
12.5/12.8
Outdoor unit Unit model
RAS -16J2AVG-E
Dimension Height (mm) 550
Width (mm) 780
Depth (mm) 290
Net weight (kg) 30
Compressor Motor output (W) 750
Type
Model KSN108D22UFZ
Fan motor output (W) 43
Air flow rate (Cooling / Heating)
(m
3
/ min)
36/36
Piping Type Flare connection
connection Indoor unit Liquid side (mm)
6.35
Gas side (mm)
12.7
Outdoor unit Liquid side (mm)
6.35
Gas side (mm)
12.7
Maximum length (m) 20
Maximum charge-less length (m) 15
Maximum height difference (m) 12
Refrigerant Name of refrigerant
R32
Weight (kg) 0.62
Wiring Power supply 3 Wires: Includes earth (Outdoor)
connection Interconnection 4 Wires: Includes earth
Usable temperature range Indoor (Cooling / Heating) 21-32/ -28
Outdoor (Cooling / Heating)
(C)
-15,46/-15,24
1.30-6.00
1.20-4.70
5.00
4.20
6.35 6.41
2-1. Specification
Single rotary type with DC-inverter variable speed control
* The specification may be subject to change without notice for purpose of improvement.
(
o
C)
Accessory Indoor unit
Installation plate 1
Wireless remote controller 1
Batteries
2
Remote controller holder 1
Active Carbon Catechin filter
-
Mounting screw
6(4x25L)
Remote controller holder
Flat head wood screw
Installation manual 1
Owner's manual
1
2(3.1x16L)
RAS-18J2KVG-E
RAS-18J2AVG-E
1Ph/50Hz/220-240V
Co o ling H ea ting
0.34-0.32 0.34-0.32
50 50
66 66
Cooling Heating
6.91-6.33 7.16-6.58
15
00 1550
99 98
3.23/3.38
47/48
40/40
32/32
50/52
RAS-18J2KVG-E
293
798
230
9
30
13.3/14.0
RAS-18J2AVG-E
5
50
780
290
34
750
KSN108D22UFZ
43
36/36
Flare connection
6.35
12.7
6.35

12.7
20
15
12
R32
0.88
21-32/ -28
-15,46/-15,24
1.00-6.00
1.30-5.50
5.40
5.00
7.25-6.65 7.50-6.90
1
1
2
1
-
6(4x25L)
1
1
2(3.1x16L)
