5. SPECIFICATIONS OF ELECTRICAL PARTS
5-1. Outdoor Unit
RAV-GP801AT*
No. Parts name Type Specifications
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Compressor
Outdoor fan motor
4-way valve coil
PMV coil
High pressure switch
Compressor thermostat
Reactor
P.C.board
P.C.board(LED display)
Outdoor temp. sensor (TO sensor)
Discharge temp. sensor (TD sensor)
Suction temp. sensor (TS sensor)
Heat exchanger temp. sensor (TE sensor)
Heat exchanger mid. temp. sensor (TL sensor)
Fuse (Mounted on P.C.board, MCC-1705)
Fuse (Mounted on P.C.board, MCC-1705)
Fuse (Mounted on P.C.board, MCC-1705)
Relay
NX220A1F-20N
ICF-280-A60-1
STF-H01AZ1724A1
UKV-A040
ACB-4UB83W
US-622
CH-101
MCC-1705
MCC-1646
GDT250V25A-A
SCT3.15A
50T100H
DX12D1-0(M)
—
—
—
—
—
—
—
—
DC280V, 60W
DC12V
DC12V
OFF:4.15MPa
OFF:125 ± 4˚C , ON:90 ± 5˚C
10mH, 20A
10kΩ at 25˚C
1.905kΩ at 120˚C
10kΩ at 25˚C
10kΩ at 25˚C
1.905kΩ at 120˚C
25A, 250V
3.15A, 250V
10A, 250V
20A, 250V
No. Parts name Type Specifications
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Compressor
Outdoor fan motor
4-way valve coil
PMV coil
High pressure switch
Compressor thermostat
Reactor
P.C.board
P.C.board(LED display)
Outdoor temp. sensor (TO sensor)
Discharge temp. sensor (TD sensor)
Suction temp. sensor (TS sensor)
Heat exchanger temp. sensor (TE sensor)
Heat exchanger mid. temp. sensor (TL sensor)
Fuse (Mounted on P.C.board, MCC-1705)
Fuse (Mounted on P.C.board, MCC-1705)
Fuse (Mounted on P.C.board, MCC-1705)
Relay
DX380A2T-20M
ICF-280-A100-1
STF-H01AZ1724A1
UKV-A040
ACB-4UB83W
US-622
CH-101
MCC-1705
MCC-1646
GDT250V25A-A
SCT3.15A
50T100H
DX12D1-0(M)
—
—
—
—
—
—
—
—
DC280V, 100W
DC12V
DC12V
OFF:4.15MPa
OFF:125 ± 4˚C, ON:90 ± 5˚C
10mH, 20A
10kΩ at 25˚C
1.905kΩ at 120˚C
10kΩ at 25˚C
10kΩ at 25˚C
1.905kΩ at 120˚C
25A, 250V
3.15A, 250V
10A, 250V
20A, 250V
RAV-GP1101AT*,GP1401AT*
