Concealed Duct High Static Pressure
Owner’s Manual
EN
2 PARTS NAME
Indoor unit
Outdoor unit
* The image of outdoor unit in the figure is in case Model RAV-SM1403AT-E.
Air outlet
Connect a discharge duct.
SET
TIME
TIMER SET
TEST
FILTER
RESET
CL
FAN
SAVE
SWING/FIX
VENT
MODE
UNIT LOUVER
Remote controller
Separate sold part
Air heat exchanger
Air inlet
Connect a suction duct.
Drain pan
Drain pipe connector
Refrigerant pipe connector
Power input
Electric parts box
The earth screw is provided in the electric
parts box.
Air inlet (Side and rear)
Air outlet
Pipes and electric
wires
4-EN
